Car Speaker

Loudspeaker YD160-5-4F50U 160mm 6.5 Inch 4ohm 25W Car Speaker Drivers Stereo Sound Used for Audio System Car Door Speaker High End Speaker Manufacturer

  • ModelYD160-5-4F50UDiameter: 160mmCone Material: PaperEdge: FoamNominal Power: 25WMaximum Power: 30WImpedance: 415%ΩFo: 8020%HzResponse: Fo-15kHzS.P.L: 893dB/W/MMagnet Size: Φ50Φ2210Net weight:

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD160-5-4F50U
  • Diameter: 160mm
  • Description
  • Order

Product Description

YD160-5-4F50U-Model


ModelYD160-5-4F50U
Diameter: 160mm
Cone Material: Paper
Edge: Foam
Nominal Power: 25W
Maximum Power: 30W
Impedance:  4±15%Ω
Fo: 80±20%Hz
Response: Fo-15kHz
S.P.L: 89±3dB/W/M
Magnet Size: Φ50×Φ22×10
Net weight:

YD160-5-4F50U-Q
