Car Speaker

Loudspeaker YD158-63-4F70RPP2W 158mm 6 inch 4ohm 70W Car Speaker Drivers sound Used for Audio System Car Door Speaker High end Speaker Manufacturer

  • ModelYD158-63-4F70RPP2WDiameter: 158mmCone Material: PPEdge: RubberNominal Power: 35WMaximum Power: 70WImpedance: 415%ΩFo: 7520%HzResponse: Fo-20kHzS.P.L: 873dB/W/MMagnet Size: Φ70Φ3212Net weight:

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD158-63-4F70RPP2W
  • Diameter: 158mm
  • Description
  • Order

Product Description

ModelYD158-63-4F70RPP2W
Diameter: 158mm
Cone Material: PP
Edge: Rubber
Nominal Power: 35W
Maximum Power: 70W
Impedance:  4±15%Ω
Fo: 75±20%Hz
Response: Fo-20kHz
S.P.L: 87±3dB/W/M
Magnet Size: Φ70×Φ32×12
Net weight:

YD158-63-4F70RPP2W-Q
