Loudspeaker

Loudspeaker 66mm YD66-36-4F40RT-R Min Full Range Multimedia Speaker Drivers

  • Loudspeaker 66mm YD66-36-4F40RT-R Min Full Range Multimidia Speaker Drivers-Changzhou Esuntech Co LtdModelYD66-36-4F40RT-RDimension:66*66*22H mmCone Material:PaperEdge:RubberNominal Power:10WMaximum P

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD66-36-4F40RT-R
  • PDF
  • Description
  • Order

Product Description

Loudspeaker 66mm YD66-36-4F40RT-R Min Full Range Multimidia Speaker Drivers-Changzhou Esuntech Co Ltd






ModelYD66-36-4F40RT-R
Dimension:66*66*22H mm
Cone Material:Paper
Edge:Rubber
Nominal Power:10W
Maximum Power:12W
Impedance:4±15%Ω
Voice coil:Φ14.28mm KSV+Cu
Fo:165±20%Hz
Response:Fo~20KHZ
S.P.L:89±3dB(AT 0.1M/0.1W, AT 0.6,0.8,1.0,1.2KHZ)
Magnet Size:Φ40*19*8mm + Φ32*18*6mm
Net weight:157g±8%
