Loudspeaker YD50-22-4N12.5U 2 Inch 4 Ohm 1W Loudspeaker Drivers

  • Model YD50-22-4N12.5U Diameter: Φ50mmCone Material:PaperEdge:FoamNominal Power: 1wMaximum Power: 2wImpedance: 415%ΩVoice coil:Φ13.3mm Fo:18020%HzResponse:F

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD50-22-4N12.5U
  • PDF
  • Description
  • Order

Product Description

HTB1VuE1XvLsK1Rjy0Fbq6xSEXXaM

                          Model

                  YD50-22-4N12.5U

Diameter:

Φ50mm

Cone Material:

Paper

Edge:

Foam

Nominal Power:

1w

Maximum Power:

2w

Impedance:

4±15%Ω

Voice coil:

Φ13.3mm

Fo:

180±20%Hz

Response:

Fo-10kHz

S.P.L:

79±3dB/W/M

Magnet Size:

Φ12.5×3(NdFeB)

Net weight:

30.5g

3
