Car Speaker

Loudspeaker YD158-63-4F70U 158mm 6 6.2 Inch 4ohm 35W Car Speaker Drivers Surround Sound Used for Audio System Car Door Speaker High End Speaker Manufacturer

  • ModelYD158-63-4F70UDiameter: 158mmCone Material: PaperEdge: FoamNominal Power: 35WMaximum Power: 70WImpedance: 415%ΩFo: 9520%HzResponse: Fo-15kHzS.P.L: 883dB/W/MMagnet Size: Φ70Φ3212Net weight:

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD158-63-4F70U
  • Diameter: 158mm
  • Description
  • Order

Product Description

ModelYD158-63-4F70U
Diameter: 158mm
Cone Material: Paper
Edge: Foam
Nominal Power: 35W
Maximum Power: 70W
Impedance:  4±15%Ω
Fo: 95±20%Hz
Response: Fo-15kHz
S.P.L: 88±3dB/W/M
Magnet Size: Φ70×Φ32×12
Net weight:

YD158-63-4F70U-Q
