Loudspeaker YD131-13-4F60U 131mm 5" 4ohm 15W Car Speaker Drivers Used for Audio System Car Door Speaker High Quality Speaker Manufacturer

  • ModelYD131-13-4F60UDiameter: 131mmCone Material: PaperEdge: FoamNominal Power: 15WMaximum Power: 30WImpedance: 415%ΩFo: 11020%HzResponse: Fo-15kHzS.P.L: 883dB/W/MMagnet Size: Φ55Φ2410Net weight:

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD131-13-4F60U
  • Diameter: 131mm
  • Description
  • Order

Product Description



YD131-13-4F60U-Model


ModelYD131-13-4F60U
Diameter: 131mm
Cone Material: Paper
Edge: Foam
Nominal Power: 15W
Maximum Power: 30W
Impedance:  4±15%Ω
Fo: 110±20%Hz
Response: Fo-15kHz
S.P.L: 88±3dB/W/M
Magnet Size: Φ55×Φ24×10
Net weight:
