Car Speaker

Loudspeaker YD120-30D-4F70U-R 118mm*118mm 4.7 Car Speaker drivers Used for Audio System car door speaker good quality cheap price speaker manufacturer

  • Model：YD120-30D-4F70U-RDiameter: 118.5x118.5Cone Material: PaperEdge: FoamNominal Power: 20WMaximum Power: 40WImpedance: 415%ΩFo: 9020%HzResponse: Fo-20kHzS.P.L: 883dB/W/MMagnet Size: Φ70Φ3210Net wei

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD120-30D-4F70U-R
  • Diameter: 118.5x118.5
  • Description
  • Order

Product Description

YD120-30D-4F70U-R-Model




Model：YD120-30D-4F70U-R
Diameter: 118.5x118.5
Cone Material: Paper
Edge: Foam
Nominal Power: 20W
Maximum Power: 40W
Impedance:  4±15%Ω
Fo: 90±20%Hz
Response: Fo-20kHz
S.P.L: 88±3dB/W/M
Magnet Size: Φ70×Φ32×10
Net weight:

YD120-30D-4F70U-R-Q
