Car Speaker

Loudspeaker YD100-3-4F70UL 102mm*102mm 4" Car Speaker Unit Used for Audio System

  • ModelYD100-3-4F70ULDiameter: 102x102Cone Material: PaperEdge: FoamNominal Power: 25WMaximum Power: 50WImpedance: 415%ΩFo: 13020%HzResponse: Fo-20kHzS.P.L: 893dB/W/MMagnet Size: Φ70Φ3210Net weight:

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD100-3-4F70UL
  • Diameter: 102x102
  • Description
  • Order

Product Description

YD100-3-4F70UL-Model


ModelYD100-3-4F70UL
Diameter: 102x102
Cone Material: Paper
Edge: Foam
Nominal Power: 25W
Maximum Power: 50W
Impedance:  4±15%Ω
Fo: 130±20%Hz
Response: Fo-20kHz
S.P.L: 89±3dB/W/M
Magnet Size: Φ70×Φ32×10
Net weight:

  1. YD100-3-4F70UL-Q
