Loudspeaker YD300-01-8F126U 12 Inch Bass Speaker Drivers, China Speaker Manufacturer

  • Model YD300-01-8F126UDiameter:Φ304mmCone Material:PaperEdge:FoamNominal Power:50wMaximum Power:100wImpedance:815%ΩVoice coil:Φ38.6mmFo:3520%HzResponse:Fo-1kHz

  • Availability: Available
  • Brand: Esuntech
  • MODEL: YD300-01-8F126U
  • PDF
  • Description
  • Order

Product Description

2

                          Model                 YD300-01-8F126U

Diameter:

Φ304mm

Cone Material:

Paper

Edge:

Foam

Nominal Power:

50w

Maximum Power:

100w

Impedance:

8±15%Ω

Voice coil:

Φ38.6mm

Fo:

35±20%Hz

Response:

Fo-1kHz

S.P.L:

95±3dB/1W/0.5M

Magnet Size:

Φ126×60×20(Ferrite)

Net weight:

2150g
