Mini Speaker

small wiring speaker ESP15N miniature speaker

  • 15mmx4mm mini speaker 850hz 1540 1504 mylar speaker annunciator transducer & buzzer high quality alarm buzzer for household electrical appliances,medical,meter and instrument - Changzhou Esuntech

  • Availability: Available
  • Brand: Esuntech
  • MODEL: ESP15N-01
  • Diameter: 15mmx4mm
  • PDF
  • Description
  • Order

Product Description

15mmx4mm   mini  speaker 850hz 1540 1504 mylar speaker annunciator transducer & buzzer  high quality  alarm buzzer for household electrical appliances,medical,meter and instrument - Changzhou Esuntech Co Ltd.


2

Model No.ESP15N-01
Cone Material: mylar
Edge:
Nominal Power: 0.6w
Maximum Power: 1.0w
Impedance: 8 ohm±15%Ω
Fo: 850hz
Response: Fo-20kHz
S.P.L:  89±3dB/W/M
Magnet Size: NdFeB
RohsYes

3
