Mechanical Buzzer

SMD Piezo eletric buzzer EPB1710S 12VDC piezo

  • 17mmx10mm 12V 1710 1701 SMD passive piezo transducer & buzzer round buzzer buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd. Model No.EPB

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EPB1710S-HL-12-4.0-R
  • Diameter: 17mmx10mm
  • PDF
  • Description
  • Order

Product Description

17mmx10mm 12V 1710 1701  SMD passive piezo transducer & buzzer round buzzer buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EPB1710S-HL-12-4.0-R
Rated Voltage (VDC)12
Max Input Voltage (VDC)3~20
Rated Current (mA)≤12
Resonance Frequency (KHz)4.0±0.5
Capacitance at 120Hz (pF)12000±30%
Sound Output at 10cm (dB)≥85
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+85
Weight (g)2
Housing MaterialLCP
RoHSYes

3
