SMD Piezo Transducer

SMD Piezo buzzer EPT1870S-HS-3.6-2.0-25-R surface mount package

  • 18mm*7mm 3.6V 1870 1807 SMD passive piezo transducer & buzzer square buzzer buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.Model No.EPT1870S-H

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EPT1870S-HS-3.6-2.0-25-R
  • Diameter: 18mm*7mm
  • PDF
  • Description
  • Order

Product Description

18mm*7mm 3.6V 1870 1807  SMD passive piezo transducer & buzzer square buzzer buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EPT1870S-HS-3.6-2.0-25-R
Rated   Voltage (Vp-p)3.6
Operating   Voltage (Vp-p)1～25
Resonant   Frequency (Hz)2000±500
Static   Capacitance at1KHz (PF)25000±30%
*Sound   Output at 10cm (dB)≥75
*Current   Consumption (mA)≤8
Operating   Temperature (℃)-20～+70
Storage   Temperature (℃)-30～+85
Weight   (g)2
Housing   MaterialPPS
RoHSYes
