SMD Piezo Transducer

SMD Piezo buzzer EPT1760CS-HS-12-4.0-15-R 4KHZ transducer

  • 17mm*6mm 12V 1760 1706 SMD passive piezo transducer & buzzer square buzzer buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.Model No.EPT1760CS-HS

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EPT1760CS-HS-12-4.0-15-R
  • Diameter: 17mm*6mm
  • PDF
  • Description
  • Order

Product Description

17mm*6mm 12V 1760 1706 SMD passive piezo transducer & buzzer square buzzer buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EPT1760CS-HS-12-4.0-15-R
Rated Voltage (Vp-p)12
Max Input Voltage (Vp-p)30
*Rated Current (mA)≤10
Resonance Frequency (Hz)4000±500
Capacitance at 120Hz (pF)15000±30%
*Sound Output at 10cm (dB)≥90
Operating Temperature (℃)-20～+75
Storage Temperature (℃)-30～+85
Weight (g)2
Housing MaterialPPS
RoHSYes
