SMD Elec-Magnet Transducer

SMD magnetic transducer EET7520AS 7.5x7.5x2mm High-Output Alarm Annunciator buzzer

  • 7.5mmx7.5mmx2.mm 3.6V 2700hz 7520 SMD passive electromagnetic transducer & buzzer square buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EET7520AS-3.6-2.7-12-R
  • Diameter: 7.5mmx7.5mmx2.mm
  • PDF
  • Description
  • Order

Product Description

7.5mmx7.5mmx2.mm 3.6V  2700hz 7520  SMD passive electromagnetic transducer & buzzer square  buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


Model No.EET7520AS-3.6-2.7-12-R
Rated Voltage (V)3.6
Operating Voltage (V)2.0-5.0
Rated Current (mA)≤120
Resonance Frequency (Hz)4000
Coil Resistance (Ω)12±3
Sound Output at 10cm (dB)≥82
Operating Temperature (℃)-40～+85
Storage Temperature (℃)-50～+95
Weight (g)0.8
Housing MaterialLCP
RohsYes
