SMD Elec-Magnet Transducer

SMD magnetic transducer buzzer EET8536CS-03L-2.730-18-R High-Output Alarm Annunciator

  • 8.5mmx6.5mmx3.6mm 3V 2730hz 8536 SMD passive electromagnetic transducer & buzzer square buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

8.5mmx6.5mmx3.6mm 3V  2730hz 8536  SMD passive electromagnetic transducer & buzzer square  buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EET8536CS-03L-2.730-18-R
Rated Voltage (V)3
Max Input Voltage (V)2~5
Coil Resistance (Ω)18±3
Rated Current (mA)80 at Rated Voltage
Resonance Frequency (Hz)2730
Sound Output at 10cm (dB)85 at10cm at Rated Voltage
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)0.5
Housing MaterialLCP/BLACK
RohsYes

3
