SMD Elec-Magnet Transducer

SMD magnetic transducer buzzer EET7525AS-3.6L-2.7-15-R High-Output Alarm Annunciator

  • 7.5mmx7.5mmx2.5mm 3V 4khz 7525 SMD passive electromagnetic transducer & buzzer square buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

7.5mmx7.5mmx2.5mm 3V  4khz 7525  SMD passive electromagnetic transducer & buzzer square  buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EET7525AS-3.6L-2.7-15-R
Rated Voltage (V)3.6
Operating Voltage (V)2.5-4.5
Rated Current (mA)≤100
Resonance Frequency (Hz)2700
Coil Resistance (Ω)15±3
Sound Output at 10cm (dB)≥85
Operating Temperature (℃)-20～+105
Storage Temperature (℃)-30～+120
Weight (g)0.3
Housing MaterialLCP
RohsYes

3
