SMD Elec-Magnet Buzzer

SMD magnetic buzzer EEB1370ES-05S-2.3-R 5V built-in buzzer

  • 13mmx13mmx7mm 5V 2300hz 1370 1307 SMD active electromagnetic transducer & buzzer square buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

13mmx13mmx7mm 5V  2300hz 1370 1307  SMD active electromagnetic transducer & buzzer square  buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EEB1370ES-05S-2.3-R
Rated Voltage (V)5
Operating Voltage (VDC)3~8
*Resonant Frequency (KHz)2.3±0.3
*Sound Output at 10cm (dB)≥88
*Current Consumption (mA)≤30
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)1
Housing MaterialLCP
RohsYes

3
