SMD Elec-Magnet Transducer

SMD electromagnetic buzzer EET9032BS-03L-2.7-16-R passive magnetic transducer

  • 9mmx3.2mm 3V 2700hz 9032 SMD passive electromagnetic transducer & buzzer square buzzer Annunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

9mmx3.2mm 3V  2700hz 9032  SMD passive electromagnetic transducer & buzzer square  buzzer Annunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EET9032BS-03L-2.7-16-R
Rated Voltage (V)3
Max Input Voltage (V)2~4
Coil Resistance (Ω)16±3
Resonance Frequency (Hz)2700
Sound Output at 10cm (dB)≥92
*Current Consumption (mA)≤80
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)0.8
Housing MaterialPPS
RohsYes

3
