SMD Elec-Magnet Transducer

SMD electromagnetic buzzer EET9025BS-03L-2.731-16-R High-Output Alarm transducer

  • 9mmx2.5mm 3V 2731hz 9025 SMD passive electromagnetic transducer & buzzer square buzzer Annunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

9mmx2.5mm 3V  2731hz 9025  SMD passive electromagnetic transducer & buzzer square  buzzer Annunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EET9025BS-03L-2.731-16-R
Rated Voltage (V)3
Max Input Voltage (V)2~5
Coil Resistance (Ω)16±3
Rated Current (mA)≤80
Resonance Frequency (Hz)2731
*Current Consumption (mA)≥88
Sound Output at 10cm (dB)≤85
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)0.8
RohsYes
