SMD Elec-Magnet Transducer

SMD electromagnetic buzzer EET8835S-3.6L-2.73-20-R High-Output Alarm Annunciator

  • 8.8mmx8.8mmx3.5mm 3.6V 2730hz 8836 SMD passive electromagnetic transducer & buzzer square buzzer Annunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntec

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

8.8mmx8.8mmx3.5mm 3.6V  2730hz 8836  SMD passive electromagnetic transducer & buzzer square  buzzer Annunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EET8835S-3.6L-2.73-20-R
Rated Voltage (V)3.6
Max Input Voltage (V)2.5~5.5
Rated Current (mA)≤80
Coil Resistance (Ω)20±3
Resonance Frequency (Hz)2730
*Sound Pressure Level (dB/min)88 at10cm at Rated Voltage
*Current Consumption (mA/max)100 at Rated Voltage
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)0.8
RohsYes
