SMD Elec-Magnet Transducer

SMD electromagnetic buzzer EET1370FS-05L-2.4-47-R 5v passive transducer

  • 13mmx13mmx7mm 5V 1370 1307 SMD passive electromagnetic transducer & buzzer square buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd. Mode

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

13mmx13mmx7mm 5V 1370 1307  SMD passive electromagnetic transducer & buzzer square  buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

Model No.EET1370FS-05L-2.4-47-R
Rated Voltage (V)5
Operating Voltage (V)3～7
Coil Resistance/DC (Ω)47±6
Resonant Frequency (Hz)2400
*Sound Output at 10cm (dB)Min.90
*Current Consumption (mA)≤40
Operating Temperature (℃)-40～+80
Storage Temperature (℃)-40～+80
Weight (g)2
Housing MaterialLCP
RoHSYes
