SMD Elec-Magnet Transducer

SMD electromagnetic buzzer EET1310FS-12L-2.4-140-R 5v magnetic transducer

  • 13mmx13mmx10mm 5V 1310 1301 SMD passive electromagnetic transducer & buzzer square buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd. Mod

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EET1310FS-12L-2.4-140-R
  • Diameter: 13mmx13mmx10mm
  • PDF
  • Description
  • Order

Product Description

13mmx13mmx10mm 5V 1310 1301  SMD passive electromagnetic transducer & buzzer square  buzzer high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


Model No.EET1310FS-12L-2.4-140-R
Rated Voltage (V)12
Operating Voltage (V)8~16
Coil Resistance/DC (Ω)140±10
Resonance Frequency (Hz)2400
*Sound Output at 10cm (dB)Min.90
*Current Consumption (mA)≤40
Operating Temperature (℃)-40～+80
Storage Temperature (℃)-40～+80
Weight (g)2
Housing MaterialLCP
RoHSYes
