Product Description

42mmx16mm Piezo wired buzzer  6V 12V 24V 2800hz 4216 continuous tone alarm annunciator  transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2


ModelEPB4216SW1405-TA-12-2.8-R
Rated Voltage (VDC)12
Operating Voltage (VDC)3～20
*Rated Current (mA)≤12
*Sound Output at 30 cm (dB)≥100
*Resonant Frequency (Hz)2800±500
ToneContinuous
Operating Temperature (℃)-20 ～ +65
Storage Temperature (℃)-30 ～ +70
Weight (g)14
RoHSYes
