Piezo Buzzer

Piezoelectric buzzer EPB2413 6V 9 V 12V buzzer wiring

  • 24mmx13mm Piezo wired buzzer with wire 6V 12V 24V 3300hz 2413 alarm annunciator transducer & buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

24mmx13mm Piezo wired buzzer with wire  6V 12V 24V 3300hz 2413 alarm annunciator  transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2


ModelEPB2413W905-TO-12-3.3-R
Rated Voltage (VDC)12
Operating Voltage (VDC)3～20
Resonant Frequency (Hz)3300±500
*Sound Output at 10cm (dB)≥90
*Current Consumption (mA)≤15
Operating Temperature (℃)-20～+60
Storage Temperature (℃)-30～+70
Weight (g)3.8
Housing MaterialPPO
RoHSYes

3
