Piezo Transducer

Piezo wireless annunciator EPT5216-TP-18-2.0-250-R 18V high-output alarm buzzer supplier

  • 52mmx16mm 3 pin buzzer 12V 18V 2Khz 5216 alarm annunciator passive piezo transducer & buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EPT5216-TP-18-2.0-250-R
  • Diameter: 52mmx16mm
  • PDF
  • Description
  • Order

Product Description

52mmx16mm 3 pin buzzer  12V 18V 2Khz 5216 alarm annunciator  passive piezo transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


Model No.EPT5216-TP-18-2.0-250-R
Rated Voltage (Vp-p)18
Allowable lnput Voltage (Vp-p)60
Capacitance 120Hz (PF)250000±30%
*Sound Output at 300cm (dB)≥95
*Current Consumption (mA)≤150
*Resonant Frequency (Hz)2000
Operating Temperature (℃)-20 ～ +105
Weight (g)14
RoHSYes
