Piezo Buzzer

Piezo wired buzzer EPB3095W1503-TA-12-3.4-R 6V 12V 24V pulse tone buzzer

  • 30mmx9.5mm continuous pulse tone sound buzzer 6V 12V 24V 3400hz 3095 alarm annunciator active piezo transducer & buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzh

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

30mmx9.5mm continuous pulse tone sound buzzer  6V 12V 24V 3400hz 3095 alarm annunciator active piezo transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2


Model No.EPB3095W1503-TA-12-3.4-R
Rated Voltage (VDC)12
Operating Voltage (VDC)3～20
*Resonant Frequency (Hz)3400±500
*Sound Output at 10cm (dB)≥90
*Current Consumption (mA)≤15
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+70
Weight (g)5.5
RoHSYes

3
