Piezo Buzzer

Piezo wired buzzer EPB3024 6V 12V 24V pulse tone buzzer

  • 30mmx24mm continuous pulse tone sound buzzer 6V 12V 24V 3500hz 3020 3002 alarm annunciator active piezo transducer & buzzer high quality alarm buzzer,alarm for household electrical appliances - Cha

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

30mmx24mm continuous pulse tone sound buzzer  6V 12V 24V 3500hz 3020 3002 alarm annunciator active piezo transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2


Model NO.EPB3024PW1505-TA-12-3.5-R
Rated Voltage (VDC)12
Operating Voltage (VDC)2～30
*Resonant Frequency (Hz)3500±500
*Sound Output at 30cm (dB)≥95
*Current Consumption (mA)≤12
Tone / Pulse Rate165±20 times/min.
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)13
Housing MaterialBlack ABS
RoHSYes

3
