Piezo Transducer

piezo electric buzzer EPT4216W-TA-09-2.8-35-R wired piezo annunciator

  • 42mmx16mm wired buzzer 3V 6V 12V 2800hz 4216 alarm annunciator passive piezo transducer & buzzer with wire high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech C

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EPT4216W-TA-09-2.8-35-R
  • Diameter: 42mmx16mm
  • PDF
  • Description
  • Order

Product Description

42mmx16mm wired buzzer 3V 6V 12V 2800hz 4216  alarm annunciator  passive piezo transducer & buzzer with wire high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


Model No.EPT4216W-TA-09-2.8-35-R
Rated Voltage (Vp-p)9
Operating Voltage (Vp-p)1～30
Resonant Frequency (Hz)2800±500
Static Capacitance at1KHz (PF)35000±30%
*Sound Output at 10cm (dB)≥90
*Current Consumption (mA)≤3
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)10
Housing Material
RoHSYes
