Piezo Buzzer

Piezo electric buzzer EPB4333SP-TA-12-2.9-7.5-R big power buzzer

  • 43mmx33mm Piezo buzzer 2/3 pin continuous pulse tone 2900hz 4333 alarm annunciator transducer & buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Lt

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

43mmx33mm Piezo buzzer 2/3 pin continuous pulse tone 2900hz 4333 alarm annunciator  transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

ModelEPB4333SP-TA-12-2.9-7.5-R
Rated Voltage (VDC)12
Operating Voltage (VDC)5～28
*Rated Current (mA)≤20
*Sound Output at 30cm (dB)≥95
*Resonant Frequency (Hz)2900±500
ToneFast Pulse /Continuous
Operating Temperature (℃)-20～+65
Storage Temperature (℃)-30～+70
Weight (g)38
Housing MaterialABS
RoHSYes
