Piezo Transducer

Piezo buzzer speaker EPG3812 anti animal buzzer

  • 38mmx12mm piezo speaker buzzer 5.5V 25khz DG38 anti mouse mosquito dog annunciator passive piezo transducer & buzzer with wire high quality alarm buzzer,alarm for household electrical appliances - C

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EPG3812
  • Diameter: 38mmx12mm
  • PDF
  • Description
  • Order

Product Description

38mmx12mm piezo speaker buzzer 5.5V 25khz DG38 anti mouse mosquito dog annunciator  passive piezo transducer & buzzer with wire high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


Model No.EPG3812
Rated Voltage (Vrms)5.5
Operating Voltage (Vrms)30
*Resonant Frequency (Hz)25000±5000
Capacitance 120Hz (PF)140000±40%
*Sound Output at 30cm (dB)≥95
Operating Temperature  (℃)-20～+70
Storage Temperature  (℃)-30～+80
Weight  (g)4.5
RohsYes
