Piezo Buzzer

Piezo buzzer EPB4314-TB-12-2.8-25.4-R big sound anunciator active buzzer

  • 43mmx14mm Piezo buzzer 6V 9V 12V 24V 2800hz 4314 alarm annunciator transducer & buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd. Model

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

43mmx14mm Piezo buzzer  6V 9V 12V 24V 2800hz 4314 alarm annunciator  transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

ModelEPB4314-TB-12-2.8-25.4-R
Rated Voltage (VDC)12
Operating Voltage (VDC)3～20
*Rated Current (mA)≤15
*Sound Output at 30 cm (dB)≥100
*Resonant Frequency (Hz)2800±500
ToneContinuous
Operating Temperature (℃)-20 ～ +60
Storage Temperature (℃)-30 ～ +70
Weight (g)11.5
RoHSYes
