Electro Magnetic Transducer

magnetic transducer EET1450 passive magnetic anunciator

  • 14mmx5mm 3V 140 OHM 2000hz 1450 1405 passive electromagnetic transducer & buzzer square buzzer Annunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EET1450-030-2.0-40-7.6-R
  • Diameter: 14mmx5mm
  • PDF
  • Description
  • Order

Product Description

14mmx5mm 3V  140 OHM 2000hz 1450 1405  passive electromagnetic transducer & buzzer square  buzzer Annunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


ModelEET1450-030-2.0-40-7.6-R
Rated Voltage (V)3
Operating Voltage (V)2～5
Coil Resistance (Ω)40±10
*Sound Output at 10cm (dB)≥85
*Current Consumption (mA)≤50
Resonant Frequency (Hz)2000
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+75
Weight (g)2
RohsYes
