Electro Magnetic Transducer

magnetic electric buzzer EET1265 wired annunciator

  • 12mmx6.5 wired buzzer 1.3V 3500hz 1265 alarm annunciator passive piezo transducer & buzzer with wire high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EET1265W253-1.3O-3.5-16-R
  • Diameter: 12mmx6.5mm
  • PDF
  • Description
  • Order

Product Description

12mmx6.5 wired buzzer 1.3V 3500hz 1265 alarm annunciator  passive piezo transducer & buzzer with wire high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2



ModelEET1265W253-1.3O-3.5-16-R
Rated Voltage (V)1.3
Operating Voltage (V)2～5
Resonant Frequency (Hz)3200--3700
Coil Resistance (Ω)16±3
*Sound Output at 30cm (dB)≥85
*Current Consumption (mA)≤30
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+85
Weight (g)1.5
RoHsYes




3
