Electro Magnetic Transducer

magnetic buzzer EET2513 high sound magnetism transducer

  • 25mmx13mm 12V 110 OHM 740hz 2513 passive electromagnetic transducer & buzzer square buzzer Anunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Lt

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EET2513B-120-0.74-110-10.2-R
  • Diameter: 25mmx13mm
  • PDF
  • Description
  • Order

Product Description

25mmx13mm 12V  110 OHM 740hz 2513  passive electromagnetic transducer & buzzer square  buzzer Anunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


ModelEET2513B-120-0.74-110-10.2-R
Rated Voltage 12V
Operating Voltage 8～16V
Resonant frequency(HZ)740
*Sound Output at 10cm (dB)  87--93dB
*Current consumption≤55mA
Coil Resistance 110±10Ω
Operating Temperature (℃)-40～+85
Storage Temperature (℃)-40～+85
Weight (g)8
RohsYes
