Electro Magnetic Transducer

Electromagnetic buzzer EET1295 passive magnetic anunciator

  • 12mmx9.5mm 5V 40 OHM 2048hz 1295 passive electromagnetic transducer & buzzer square buzzer Annunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Lt

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EET1295-050-2.048-40-6.5-R
  • Diameter: 12mmx9.5mm
  • PDF
  • Description
  • Order

Product Description

12mmx9.5mm 5V  40 OHM 2048hz 1295 passive electromagnetic transducer & buzzer square  buzzer Annunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.











ModelEET1295-050-2.048-40-6.5-R
Rated Voltage (V)5.0
Operating Voltage (V)4.5～5.5
Resonant Frequency (Hz)2048
Coil Resistance (Ω)40±5
*Sound Output at 10cm (dB)≥85
*Current Consumption (mA)≤60
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)1.3
RohsYes
