Electro Magnetic Transducer

Electromagnetic buzzer EET1285 passive magnetic anunciator

  • 12mmx8.5mm 1.3V 16 OHM 2048hz 1285 passive electromagnetic transducer & buzzer square buzzer Annunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EET1285-1.50-2.048-16-6.5-R
  • Diameter: 12mmx8.5mm
  • PDF
  • Description
  • Order

Product Description

12mmx8.5mm 1.3V  16 OHM 2048hz 1285 passive electromagnetic transducer & buzzer square  buzzer Annunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.






2



ModelEET1285-1.50-2.048-16-6.5-R
Rated Voltage (V)1.5
Operating Voltage (V)1～2
Resonant Frequency (Hz)2048
Coil Resistance (Ω)16±3
*Sound Output at 10cm (dB)≥80
*Current Consumption (mA)≤40
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)1.3
RohsYes
