Electro Magnetic Transducer

Electromagnetic buzzer EET1213 passive magnetic transducer

  • 12mmx3mm 3V 16 OHM 2400hz 1213 passive electromagnetic transducer & buzzer square buzzer Annunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EET1213B-03O-2.4-16-6.5-R
  • Diameter: 12mmx3mm
  • PDF
  • Description
  • Order

Product Description

12mmx3mm 3V  16 OHM 2400hz 1213 passive electromagnetic transducer & buzzer square  buzzer Annunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


ModelEET1213B-03O-2.4-16-6.5-R
Rated Voltage (V)3
Operating Voltage (V)2～5
Resonant Frequency (Hz)2400
Coil Resistance (Ω)16±3
*Sound Output at 10cm (dB)≥90
*Current Consumption (mA)≤80
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)1.3
RohsYes
