Electro Magnetic Buzzer

Electromagnetic buzzer EEB1614 5V active magnetic transducer

  • 16mmx14mm 3V 6V 12V 2300hz 1614 active electromagnetic transducer & buzzer square buzzer Annunciator high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EEB1614-050-2.3-7.6-R
  • Diameter: 16mmx14mm
  • PDF
  • Description
  • Order

Product Description

16mmx14mm 3V  6V 12V 2300hz 1614 active electromagnetic transducer & buzzer square  buzzer Annunciator high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.









ModelEEB1614-050-2.3-7.6-R
Rated Voltage (VDC)5
Operating Voltage (VDC)3～8
*Resonant Frequency (Hz)2300±300
*Sound Output at 10cm (dB)≥85
*Current Consumption (mA)≤30
Operating Temperature (℃)-20～+70
Storage Temperature (℃)-30～+80
Weight (g)3
Housing MaterialPPO
RohsYes
