Piezo Transducer

electricpiezo buzzer EPT3590AW1003-TA-12-1.0-50-R wired piezo transducer

  • 35mmx9mm wired buzzer 3V 6V 12V 1000hz 3590 alarm annunciator passive piezo transducer & buzzer with wire high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech C

  • Availability: Available
  • Brand: Esuntech
  • MODEL: EPT3590AW1003-TA-12-1.0-50-R
  • Diameter: 35mmx9mm
  • PDF
  • Description
  • Order

Product Description

35mmx9mm wired buzzer 3V 6V 12V 1000hz 3590   alarm annunciator  passive piezo transducer & buzzer with wire high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


Model No.EPT3590AW1003-TA-12-1.0-50-R
Rated Voltage (Vp-p)12
Operating Voltage (Vp-p)1～30
Resonant Frequency (Hz)1000±500
Capacitance 120Hz (PF)50000±30%
*Sound Output at 10cm (dB)≥85
*Current Consumption (mA)≤10
Operating Temperature (℃)-20～+60
Storage Temperature (℃)-30～+70
Weight (g)6
Case material and colourABS / Black
RoHSYes
