Piezo Buzzer

electric piezo buzzer EPB2418C 6V 9 V 12V annunciator buzzer

  • 24mmx18mm Piezo buzzer 6V 9V 12V 24V 2800hz 2418 alarm annunciator transducer & buzzer high quality alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd. Model

  • Availability: Available
  • Brand: Esuntech
  • MODEL:
  • PDF
  • Description
  • Order

Product Description

24mmx18mm Piezo buzzer  6V 9V 12V 24V 2800hz 2418 alarm annunciator  transducer & buzzer  high quality  alarm buzzer,alarm for household electrical appliances - Changzhou Esuntech Co Ltd.


2

ModelEPB2418C-TB-12-3.7-15.0-R
Rated Voltage (VDC)12
Operating Voltage (VDC)3～20
*Rated Current (mA)≤12
*Sound Output at 10 cm (dB)≥95
*Resonant Frequency (Hz)3700±500
Operating Temperature (℃)-20 ～ +70
Storage Temperature (℃)-30 ～ +80
Weight (g)5.4
Housing MaterialPBT
RoHSYes

3
